Sail Solar All In One ESS 5KW Inverter and 5KWH Lithium Battery Energy Storage System CAN Communication

Sail Solar All In One ESS 5KW Inverter and 5KWH Lithium Battery Energy Storage System CAN Communication

  • MPPT Voltage Range :

    120V~450V
  • AC Maximum Output Current :

    30A
  • Humidity :

    5%~85%
  • Frequency :

    50Hz
  • Maximum Output Current :

    30A
  • Cycle Life(+25°C 0.5C) :

    DOD 80%,10+ years design life
  • Protocol (optional) :

    RS232/RS485/CAN/BLUETOOTH/WIFI
  • Solar Charge Type :

    MPPT
  • Rated Output Power :

    5000W
  • Communication Port :

    CAN, RS485
  • Protection Class :

    IP20
  • Brand :

    Sail Solar
  • Type :

    All-in-one

SAIL SOLAR All in One Home Use Solar Power Energy Storage System is a multi-function solar inverter/solar charger, combining functions of inverter, MPPT solar charger and battery charger to offer uninterruptible power support. It is perfect backup power supply for off-grid system like household appliances, power tools, industrial equipment, and electronic audio and video equipment.

Specification

MODEL

AIO-5.12

AIO-10.24

AIO-15.36

AIO-20.48

Battery Type
LiFePO4 battery
No.of Moudle

1

2

3

4

Normal Capacity(25°c,0.2C)

5.12kwh

10.24kwh

15.36kwh

20.48kwh

Normal Voltage(dc)

51.2V

51.2V

51.2V

51.2V

Voltage Window(dc)
44.8~57.6V
Size(W/D/H)
1190x600x184mm
1800x600x184mm
1800x600x184mm
690x600x184mm
1800x600x184mm
1300x600x184mm
Weight(Nw Kg)

80

130

190

250

Normal charge/discharge current

50A

50A

50A

50A

Max.charge/discharge current

100A

100A

100A

100A

Cycle Life(+25°C 0.5C)
DOD 80%,10+ years design life
Storage Temperature
-20℃~+60°C
Safety Standard
CE/IEC/UL/UN38.3/MSDS
Protection Grade
IP20
Protocol (optional)
RS232/RS485/CAN/BLUETOOTH/WIFI
Protection
Overchange protection、Overdischange protection、 Overcurrent protection
Shortcircuit protection、Overtemperature protection
Working Temperature
Charge:0~45°c; Discharge:-10~45°C
Humidity
5%~85%
PV Charge



Solar Charge Type
MPPT
Maximum Output Power
5000W
PV Charging Current Range
0~80A
PV Operating Voltage Range
120~500V
MPPT Voltage Range
120~450V
AC Charge



Maximum Charge Power
3150W
AC Charging Current Range
0~60A
Rated input Voltage
220/230Vac
Input Voltage Range
90~280Vac
AC Output



Rated Output Power
5000W
Maximum Output Current
30A
Frequency
50Hz
Overload Current
35A
Battery Inverter Output



Rated Output Power
5000W
Maximum Peak Power
10KVA
Power Factor

1

Rated Output Voltage (Vac)
230Vac
Frequency
50Hz
Auto Switch Period
<15ms
THD
<3%

Product Description

SAIL Solar's 5.12~20.48kWh All-In-One ESS is an advanced, integrated solution that combines a three-phase hybrid solar inverter with a high-performance, low-voltage lithium battery pack, making it an ideal choice for residential use.

With a sleek and compact design, this system is not only visually appealing but also space-saving, fitting seamlessly into home environments.

Engineered for reliability, it ensures an uninterrupted power supply to keep essential devices running, even during power outages. This system also champions sustainability by storing clean, renewable energy, thus promoting an eco-friendly lifestyle while helping users reduce their carbon footprint. Additionally, it is a cost-efficient solution, enabling households to save on energy bills by optimizing solar energy use and reducing dependency on the grid. Whether for energy independence, backup power, or lowering electricity expenses, SAIL Solar's All-In-One ESS provides a powerful and efficient home energy solution.

Sail Solar 5kWh Energy Storage System (ESS) is designed to help you maximize the value of your solar energy production, with the potential to earn credits or reduce your electricity bills. The integrated lithium-ion battery pack captures any excess solar energy generated during the day, storing it for later use when it’s most needed. This stored energy is especially valuable during power outages, providing a reliable backup power source to keep essential appliances and devices running seamlessly.

Combining the capabilities of a solar inverter and an energy storage unit, this innovative system offers an all-in-one solution for both residential and small commercial applications. It's engineered for efficiency, convenience, and energy independence, allowing users to harness solar power to its fullest potential.

Certificate

Our products have been awarded various international certifications, including UN38.3, CE, IEC, UL, MSDS, and ISO, reflecting our commitment to meeting global safety and quality requirements. These certifications provide assurance that our lithium batteries are suitable for a wide range of applications and meet strict compliance guidelines. If you have any questions or specific needs regarding our products, please don’t hesitate to contact Sail Solar. We are here to help and provide the best energy solutions for your projects.
